Zitadel — Machine User & PAT

Create a Zitadel service account (machine user) and Personal Access Token (PAT) so CMP can create or link users during user migration.

The Web OIDC application's Client Secret and the machine-user PAT are different credentials:

CredentialPurpose
Client SecretEnd-user OIDC login
PATAdministrative API (create/migrate users)

Step 1 — Create service account​

Path: Zitadel Console → Users → Service Accounts → + New

Choose a Machine / Service Account user (not Human).

FieldExample / value
User Namecmp-admin
Namecmp-admin
DescriptionOptional
Access Token TypeBearer

Screenshot: New service account form

Screenshot: Service account cmp-admin with Bearer token type

Click Create.

Step 2 — Generate Personal Access Token​

Open the cmp-admin service account → Personal Access Tokens → + New.

Set an expiration date if your policy requires it. Click Add/Create and copy the token immediately.

Screenshot: Generate new Personal Access Token

Copy the PAT once

Treat the PAT as a secret. Do not commit it to source control, logs, tickets, or documentation. Store only in Admin → Settings → Social Login → Zitadel → PAT.

Step 3 — Grant permissions​

A PAT without sufficient permission can authenticate but cannot create users.

Option A — Default organization (usual setup)​

Path: Organization → use the + administrator control in the organization header.

Screenshot: Organization — add administrator

  1. Select the cmp-admin machine user
  2. Assign Org Owner
  3. Click Add

Screenshot: Add cmp-admin as Org Owner

Option B — Whole instance​

Path: Instance → Managers

  1. Add cmp-admin
  2. Assign IAM Owner

Use Option B when CMP must perform instance-level operations, including setups that create a new organization per account.

Project grants are not enough

Do not rely only on project-level grants for migration. Use Org Owner on the default organization, or IAM Owner where instance-wide access is required.

Step 4 — Save PAT in CMP​

Path: Admin → Settings → Social Login → Zitadel → Edit

Paste the PAT into the PAT field and save.

On later edits, leave PAT blank if CMP should keep the already stored token.

PAT setup checklist​

  • Service account exists (cmp-admin or equivalent)
  • Access token type is Bearer
  • PAT generated and copied securely
  • cmp-admin has Org Owner (default org) or IAM Owner (instance-wide)
  • PAT stored in CMP Social Login
  • Web OIDC Client Secret is not used as the PAT
